If you type into fields, matching items are selected automatically. Speed up selection by using lookup lists.

Set Depth Borehole / Corehole Break, to define the depth that the non cored log ends and cored log starts.

To rename a PointID, change the name in the POINT table PointID field.

Use Tab or right arrow to move to the next cell.

Note the Graphic Log option controls the log report column, set it to Graphic.

Enable Specimen Description Calc – check.

The settings on this table generally depend upon the logging standards in use, and it is critical the relevant values are set for Classification_Standard, List_Filter and Localisation_List_Filter.

If you are using BS, then both SPT Pen fields should be 75, other standards should have 150 and empty cell. Set the Project Type and SPT Pen Values to match you standard. The closest option is Cancel changes since last save, which is the save like icon with the red arrow in the top right of the screen. There is not a multi step undo like in Word. It is recommended that you save data after entering a few lines. ĭata is saved when you initiate the save by clicking on the save icon, pressing Ctrl+S, or automatically when you change tabs, or change the object selector item (yellow drop down list), or before some commands run. To enable and disable the tree navigation click on the button. You can change tables or tabs by clicking on the tabs at the top of the screen or using the tree navigation on the left. Progress through the INPUT application entering data displayed in the screen shots.

Name the new project file Tutorial.gpj, and click Save.

Browse to the data template dgdt-p #.#.#.gdt, and click Open.

Select INPUT | File > New Project or the (new) icon > Clone Data Template….

Refer to section Configure Optimal System Properties for further instruction.ĭata entry of a borehole Make a new project by cloning data template.

Launch File > System Properties, and configure the following on the first tab.

#Bentley water cad mouse will not scroll zoom trial

If you are running an evaluation or trial version, the library is read-only and the design applications are hidden.

Open the dgdt-p lib #.#.#.glb library using the command File > Change Library.

For the tutorial copy the dgdt user gINT files (*.gpj, *.gdt, *.glb, *.gcx, *.gci, *.gas) to a folder titled c:\Datgel Training\.

#Bentley water cad mouse will not scroll zoom install

Install and license gINT and the DGDT DLL program.

gINT's Application Groups and layout of program:.

How gINT communicates with other programs.

Storing, validating, manipulating and reporting data.

Database manager for subsurface exploration.

Overview of gINT Features and Capabilities.

When you have completed this tutorial, you will have gained enough skills to begin entering and importing data from a range of sources, and generating reports.

#Bentley water cad mouse will not scroll zoom how to

This tutorial explains how to complete a series of typical tasks for data entry, reporting and analysis.
